DIGITAL MANOMETER T210
12
INSTALLATION AND USE
The T210 manometer incorporates a folding support at the rear of the box that
permits the instrument to be used in an upright position, which facilitates both
use and reading.
It is recommended that the instrument be returned to its protective case when
not in use. It is also recommended that the battery be removed when the
instrument is not going to be used during a prolonged period of time.
ADJUSTMENTS
The T210 manometer leaves the factory fully adjusted and no further
adjustment is required. However, it is recommended that it be recalibrated
approximately once a year, with any necessary adjustment being carried out.
In order to correctly adjust the unit, it should be confirmed that all necessary
elements are available, such as adequately precise standards and required
means of connection.
In order to determine that the standards are adequate, consult the instrument's
technical sheet and check that the standard to be employed meets the ration
requirements, which must be greater than 2 to guarantee the correct assigned
uncertainty.
Note that a wrong choice of standard could lead to incorrect unit specifications.
If suitable standards are not available for calibration and adjustment, it should
be sent to an accredited laboratory in order to obtain a correct level of
certification and traceability. Gometrics laboratory complies with EN17025 in
pressure measurements.
Adjusting the input current
1.- Connect the instrument's measuring terminals to a current generator set
to 20 mA.
2.- Adjust with potentiometer P1 (located in the exterior section of the battery
compartment identified as I).
