DIGITAL MANOMETER T210
14
TECHNICAL SPECIFICATIONS
Pressure interval: Min: 0-25 mbar
(see table) Max: 0-1,000 bar
Uncertainty*: 0.25% FS and 0.10% FS
Current interval: ±30 mA
Uncertainty*: 0.025% of the reading + 2 µA
Resolution: 4 1/2 digits in pressure
(see table) 1 µA / 10 µA in current
Connection to process: 1/8-inch BSP M, 60º internal conical
Operating temperature: 0-50ºC
Temperature coefficient: 0.02% FS/ºC < 1 bar 0.01% FS/ºC > 1 bar
Fluids: Compatible with stainless steel and Buna N for
ranges ≥ 1 bar, air or inert gases for ranges < 1
bar and differential pressure.
Over-pressure: Twice the range. For differential pressure equal
to the maximum static. (See exception**)
Maximum static pressure: (only differential pressure), three times the
range of 14 bar (whichever is less)
Screen: 10-mm LCD
Batteries: NiMH, rechargeable
Charger power supply: 230 V, 50 Hz
Portable operation: 20 hours
Dimensions: 83 x 152 x 33 mm
Weight: 360 g
Guarantee: 3 years
Marking: CE
Calibration certificate with standard traceability (ENAC optional)
* includes non
-
linearity, hysteresis, repeatability, thermal drift between 20 and 26ºC and stability at
one year.
