DIGITAL MANOMETER T210
7
OPERATION AS MANOMETER
Proceed as described below:
1.- Check that the T210 does not have the mA reading indicator active, as
displayed on the left-hand side of the screen by a small arrow. Otherwise
press the P/mA key to change the MANOMETER/MILLI-AMMETER so
that the mA indicator is deactivated.
2.- Press the UNIT key to change the engineering units in order to verify the
working unit.
WARNING: Pressing the key a single time will display the current unit,
and by keeping it pressed, the work unit will change consecutively. See
page 10 for unit changing and the use of the memories for quick access
to programmed units.
3.- Press the yellow ZERO key if the T210 screen displays any reading other
than zero. (NOTE: For absolute sensors not applicable)
4.- Connect the instrument to be calibrated and the pressure input to the
1/8” fitting on top of the T210.
5.- The manometer is now ready to take pressure readings.
