DIGITAL MANOMETER T210
8
WARNING: The pressure connection is 1/8-inch BSP M, conical, 60º internal,
and to prevent leaks, one of the two washers supplied at the base of the fitting
connection must be used, Ref. U10351620.
NOTE: GOMETRICS has a pneumatic kit RB400BP01 together with
accessories (up to 20 bar) available that does not require any tools, tightening it
by hand and leak-tight to 20 bar.
GOMETRICS has other connection accessories available from 600 up to 1,000
bar.
OPERATION AS MILLI-AMMETER
The following instruction should be followed when using the T210 for current
readings in the 0-30 mA range, normally to verify the response of a 4-20 mA
pressure transmitter
WARNING: The T210 does not include an internal 24 Vdc power supply and
must be externally powered.
1.- Use the yellow P/mA key on the instrument's front panel to select the
current reading mode, which is indicated by the display of the mA icon on
the screen.
2.- The necessary connections should be made using the cables supplied on
the side of the T210 respecting the polarity indicated on the front panel.
3.- The instrument is now ready to take current readings in the range -30 / 0 /
+30 mA.
