Goobay TV EasyFold ML User Manual

User Manual
28 29
9  Specications
Physical size Specication Unit
TV diameter 58-147 / max. 58 cm / “
VESA max. 400x400 mm
Load max. 30 kg
Tilting angle +/-15 °
Swivel angle 80 °
Rotation angle of
VESA plate
+/-5 °
Wall distance 37-272 mm
Dimensions 450 x 450 x 37-272 mm
Weight 4.125 kg
Ta b . 2 1: Specications
10 Information for VESA standard
To harmonize attachment options of monitors, TV devices and their stands and
wall brackets in a user-friendly manner, VESA (Video Electronic Standard
Organization) dened 3 standards for the applications mentioned above. Using
the relevant VESA standard specied on your display unit, or in its user manual,
and the specications in Chapter Specications in this manual you are able to
dene the possible points of attachment. Some models allow for an innitely
variable individual attachment (e.g. 300 x 300 mm for Sony TVs).
VESA Class Hole distance for attachment of monitors
MIS-D 75x75 / 100x100 mm
MIS-E 200x100 / 200x200 mm
MIS-F 400x200 / 400x400 / 600x200 / 600x400 / 800x400 mm
Ta b . 2 2: Information for VESA standard
11 Disposal Instructions
This product should not be disposed together with domestic waste. Please
return your product free of charge at the end of its service life at the producer,
the sales outlet, or a public collection point, established for this purpose. Details
for disposal are regulated in the relevant federal state law. Potential recyclable
materials are fed into the recycling cycle to obtain new raw materials from them.
Following materials are collected a local collection points:
• Waste glass, plastic, waste metal, metal sheet, and more.
This type of recycling of waste contributes signicantly to the protection of our
environment.
