User Manual V1.4-2022-08-30 10 Technical Parameters
Max. Apparent Power Output to
Utility Grid (VA)
*2
3600/3960
*1
5000/5500
*1
6000/6600
*1
Nominal Apparent Power from
Utility Grid(VA)
7,200 10,000 12,000
Max. Apparent Power from Utility
Grid (VA)
7200(Charging
3.6kw, Backup
Output 3.6kw)
10000(Charging
5kw, Backup
Output 5kw)
12,000 (Charging
6kW, Backup
Output 6kW)
Nominal Output Voltage (V) 230/220
*6
Output Voltage Range (V) 0~300
Nominal AC Grid Frequency (Hz) 50/60
AC Grid Frequency Range (Hz) 45~65
Max. AC Current Output to Utility
Grid (A)
16/18
*1
21.7/24
*1
26.1/28.7
*1
/27.3
*7
Max. AC Current From Utility Grid (A) 32.0 43.4 52.2
Max. Output Fault Current (Peak
and Duration) (A)
65@5μs
Inrush Current (Peak and Duration)
(A)
65@5μs
Nominal Output Current (A) 15.6 21.7 26.1
Power Factor Adjustable from 0.8 leading to 0.8 lagging
Max. Total Harmonic Distortion <3%
Maximum Output Overcurrent
Protection (A)
40 54 65
AC Output Data (Back-up)
Back-up Nominal Apparent Power
(VA)
3,600 5,000 6,000
Max. Output Apparent Power (VA)
3,600 (4,320
@60sec)
5,000
(6,000@60sec)
6,000
(7,200@60sec)
Nominal Output Current (A) 15.7 21.7 26.1
Max. Output Current (A) 15.7 21.7 26.1
Max. Output Fault Current (Peak
and Duration) (A)
19@60s 26@60s 31@60s
Inrush Current (Peak and Duration)
(A)
65@5μs 65@5μs 65@5μs

Goodwe EH Plus Series Specifications

General

Brand	Goodwe
Model	EH Plus Series
Category	Inverter
Language	English
