Goodwe EH Plus Series User Manual

57
User Manual V1.4-2022-08-30 10 Technical Parameters
Max. Apparent Power from Utility
Grid (VA)
7200 (Charging
3.6kW, Backup
Output 3.6kW)
10,000
(Charging 5kW,
Backup Output
5kW)
12,000 (Charging
6kW, Backup
Output 6kW)
Nominal Output Voltage (V) 230/220
*6
Output Voltage Range (V) 0~300
Nominal AC Grid Frequency (Hz) 50/60
AC Grid Frequency Range (Hz) 45~65
Max. AC Current Output to Utility
Grid (A)
16/18
*1
21.7/24
*1
26.1/28.7
*1
/27.3
*7
Max. AC Current From Utility Grid (A) 32 43.4 52.2
Nominal AC Current From Utility Grid
(A)
32 43.4 52.2
Max. Output Fault Current (Peak and
Duration) (A)
65A @ 5μs
Inrush Current (Peak and Duration)
(A)
65A @ 5μs
Nominal Output Current (A) 15.6 21.7 26.1
Power Factor Adjustable from 0.8 leading to 0.8 lagging
Max. Total Harmonic Distortion <3%
Maximum Output Overcurrent
Protection (A)
40 54 65
Type of Voltage (a.c. or d.c.) a.c.
AC Output Data (Back-up)
Back-up Nominal Apparent Power
(VA)
3600 5000 6,000
Max. Output Apparent Power (VA)
3600 (4320
@60sec)
5000
(6000@60sec)
6,000
(7,200@60sec)
Nominal Output Current (A) 15.7 21.7 26.1
Max. Output Current (A) 15.7 21.7 26.1
Max. Output Fault Current (Peak and
Duration) (A)
65A @ 5μs
Inrush Current (Peak and Duration)
(A)
65A @ 5μs
