59
User Manual V1.4-2022-08-30 10 Technical Parameters
Topology Non-isolated
Self-consumption at Night (W)
*4
<10
Ingress Protection Rating IP65
DC Connector MC4 (4~6 mm
2
)
AC Connector Quick Plug
Environmental Category 4K4H
Pollution Degree III
Overvoltage Category DC II / AC III
Protective Class I
Storage Temperature (℃) -40~+85
The Decisive Voltage Class (DVC)
Battery: C
PV: C
AC: C
Com: A
Mounting Method Wall Mounted
Active Anti-islanding Method AFDPF + AQDPF
*8
Type of Electrical Supply System Single phase TN/TT system
Country of Manufacture China
Certications
*5
Grid Standards
VDE-AR-N 4105, G98, G100, CEI 0-21, AS/NZS4777.2,
NRS097-2-1
Safety Regulation IEC/EN 62109-1&2
EMC
EN61000-6-1, EN61000-6-2, EN61000-6-3, EN61000-6-4,
EN 61000-4-16, EN 61000-4-18, EN 61000-4-29
*1: For CEI 0-21.
*2: The grid feed in power for VDE-AR-N 4105 and NRS097-2-1 is limited 4600VA.
*3: CAN communication is congured by default. If 485 communication is used, please replace
the corresponding communication line.
*4: No Back-up Output.
*5: Not all certications & standards listed, check the ocial website for details.
*6: For Brazil, the voltage is 220V.
*7: For Brazil, the current is 27.3A.
*8: AFDPF: Active Frequency Drift with Positive Feedback, AQDPF: Active Q Drift with Positive
Feedback.
