Gooxi Purley Platform 1U User Manual

<8>
Internal storage: 1 PCIe 3.0 x4 M.2 slot, 2 Mini SSD slots (SATA DOM)
driver
Front Bay: Up to 10 hot-swap 2.5-inch SAS/SATA (HDD/SSD)
Or up to four 3.5-inch SAS/SATA (HDD/SSD)
NVMe Support: Up to 10 hot-plug 2.5-inch NVMe/SAS/SATA (SSD/HDD)
power supply
Platinum-class 550W, 800W, 1300W, 1600W hot swappable redundant power supply with
optional support for 240v and 338v DC
External Port
& PCIE
Front port: VGA, 2 USB3.0 (1U10 only supports 1), 1 LCD dedicated Mini USB
Rear: VGA, 2 USB3.0, 1 management network port, 2 RJ45 network ports
PCIE expansion board: up to 4 PCIE third generation slots
System fan
N+1 hot swap redundant fan
The internet
Two onboard 1GE, two optional 1GE/4 1GE/2 10GE/4 10GE/2 40GE network daughter
cards
safety
TPM/TCM (optional)
Chassis cover intrusion detection
Front panel with key lock
Locking the chassis cover
management
Onboard iBMC management module supporting management features such as IPMI, SOL,
KVM Over IP, and virtual media
Optional LCD Management Module
Supported
operating
systems
Microsoft Windows Server、Red Hat Enterprise Linux、SUSE Linux Enterprise Server、
CentOS、Citrix Xen Server、Vmware ESXi、Linux KVM、Ubuntu
Actual version please contact Guoxin sales
Virtualization
support
VMWare ESXi 6.0
temperature
Standard operating temperature: 5oC - 35oC (without direct sunlight)
Extended operating temperature: 5oC - 40oC (limited configuration meets)
Storage Storage Temperature: -40oC - 65oC
humidity
Operating Humidity: 30% - 80% (non-condensing)
Storage humidity: 5% - 95% (non-condensing)
