Gooxi Purley Platform 1U User Manual

<13>
3. In addition, it can also support 1* non-standard PCIEX8 SAS/RAID card slot+1*
non-standard PCIEX8 card slot;
hard disk
Supports up to 10 3.5-inch SAS/SATA (HDD/SSD)
M.2 SSD
PCIE Gen3 X4 M.2 SSD(Support M.2 SSD length 80mm and 110mm)
LAN
Two onboard 1GE, two optional 1GE/4 1GE/2 10GE/4 10GE/2 40GE network
daughter cards
External port
Front port: VGA, 1 USB3.0, 1 Mini USB for LCD
Rear: VGA, 2 USB3.0, 1 management network port, 2 RJ45 network ports
management
Onboard iBMC management module supporting management features such as
IPMI, SOL, KVM Over IP, and virtual media
Optional LCD Management Module
System fan
N+1 hot swap redundant fan
power supply
Platinum-class 550W, 800W, 1300W, 1600W hot swappable redundant power
supply with optional support for -48V, 240V, and 338V DC
Dimensions
1Ucabinet type, standard guide rails, maximum depth: 788 mm, including 808 mm
lugs
2.4 System components introduction
2.4.1 Front panel components
 1U4 bay 3.5 inch disk model
1
Built-in DVD drive
4
LCD dedicated interface
2
VGA interface
5
hard disk
3
USB 3.0 interface
6
Tag card
 1U10 disk position 2.5 inch disk model
