Gorgy Timing LEDI 1.60 - Stand-Alone Version; Parallel Min. Receiving Version; Serial ½ Min. Receiving Version; AFNOR NFS 87500 Receiving Version

19
MDE-LEDI160S-1012V1.0
► Digital display with Hour, Minute, Second (option “S”), 7 segments with electrolumines-
cent diodes.
► Height of hour and minute numbers: 18mm
► inclination of numbers 10°
► Legibility: to 7 metres
► Supply 230 VAC (+/-10%) 50-60Hz. (via remote transformer)
► Consumption: 6 Watts
► Power reserve of 48 hours with incorporated Ni-Cad battery.
EXISTING VERSIONS:
1.1. STAND-ALONE VERSION
► Incorporated quartz 3.6864Mhz time base, stability +/-0.02 sec/24hrs. between
20°C and 30°C
1.2. PARALLEL MIN. RECEIVING VERSION
► Minute impulse reversed 24V every minute. Impulse duration: 0.1 sec.
► Impulse consumption: 6 mA / 24V
1.3. SERIAL ½ MIN. RECEIVING VERSION
► Serial connection with external 39 Ohm shunt.
► ½ min. impulse reversed every ½ min.
► Impulse duration 0.1 sec.
► Impulse consumption: 1.25 V
► Intensity on line: 60 mA to 120 mA
1.4. AFNOR NFS 87500 RECEIVING VERSION
► Rated input level: 2.2 VDC
► Input impedance: 3.5 kohms
► Minimum input voltage: 70 mVDC
ENGLISH
