Gorilla Playsets Playmaker - 2400 - STEP 08

STEP 8: ATTA C HING PA NEL BO ARDS
1: THE 2 X 4 X 48" PANEL BO A RDS (WITH TWO PRE-DRILLED HO LES) ATTA C H TO THE SET O F
HO LES BELO W THE REA R TA RP SUPPO RT BO A RD O N THE REAR O F THE FO RT W ITH 4" HEX BO LTS
A ND 5/ 16" W A SHERS.
HO LES SHO ULD BE O FFSET DO W N O N THE TO P BO A RD.
HO LES SHO ULD BE O FFSET UP O N THE BO TTO M BO A RD.
REA R TA RP SUPPO RT
5/ 16" WASHER
(O FFSET DO W N)
BO A RD
PA NEL
4" HEX BO LT
5/ 16" WASHER
2 X 4 X 48"
(O FFSET UP)
4" HEX BO LT
2 X 4 X 48"
PA NEL
BO A RD
REA R O F PLAY SET
