Gorilla Playsets Playmaker - 2400 - STEP 18

BO LT C O VER
3/ 8" LO C K NUT
3/ 8" X 6-1/ 2" C A RRIAG E BO LT
3/ 8" W ASHER
TO RQ UE WASHER
SWING BEAM MO UNT
FRO NT O F PLAY SET
(A RC HED BO ARD)
TRAP A RM
BO LT C O VER
3/ 8" LO C K NUT
3/ 8" W ASHER
TO RQ UE WASHER
4 X 4 X 73-1/ 2"
3/ 8" X 6-1/ 2" C A RRIAG E BO LT
FRO NT O F PLAY SET
(A RC HED BO ARD)
STEP 18: A TTAC HING THE SWING BEAM SUPPO RT AND TRAP A RM
1: THE 4 X 4 X 36" SWING BEAM MO UNT HA S C O UNTER-SUNK HO LES IN THE C ENTER A ND O N
THE ENDS. INSTALL THE SWING BEAM MO UNT SO THAT THE C O UNTER-SUNK HO LES O N EAC H
END O F THE BEAM FAC E O UT, A ND THE C O UNTER-SUNK HO LES A T THE C ENTER FAC E DO WN.
2: FASTEN THE SWING BEAM MO UNT TO THE C O RNER PO STS USING 3/ 8" X 6-1/ 2" C A RRIA G E
BO LTS WITH TO RQ UE WASHERS. PLAC E THE C ARRIA G E BO LT INTO THE TO RQ UE WA SHER, THEN
INTO THE HO LE O F THE C O RNER PO ST A ND SET WITH A HA MMER, USE 3/ 8" W A SHERS WITH 3/ 8"
LO C K NUTS TO SEC URE THE SWING BEAM MO UNT FRO M THE O UTSIDE. PLA C E BO LT C O VERS
O VER THE EXPO SED THREADS AFTER SEC URING .
3: THE 4 X 4 X 73-1/ 2" TRAP ARM W ILL A TTA C H TO THE UNIT IN THE SA ME MANNER A S THE
SWING BEAM MO UNT. THE TRA P ARM W ILL MO UNT O N THE O PPO SITE SIDE O F THE FO RT THAT
THE SWING BEA M MO UNT W A S MO UNTED O N.
