Gorilla Playsets Playmaker - 2400 - STEP 24

STEP 24: RO C K WA LL
1: PLAC E THE RO C K W A LL INTO PO SITIO N C ENTERED O N THE RIG HT SIDE O N THE FO RT. THE BO TTO M
EDG E O F THE G REEN BRAC KETS SHO ULD BE 3/ 4" A BO VE THE BO TTO M O F THE BO TTO M PA NEL BO A RD.
USING THE BRAC KETS A S A TEMPLATE DRILL A 3/ 8" HO LE THRO UG H THE BO TTO M PA NEL BO A RD.
2: FRO M THE UNDERSIDE O F THE DEC K INSERT A T-NUT INTO THE BA C KSIDE O F THE 3/ 8" HO LES IN THE
BO TTO M PA NEL BO A RD.
3: A TTA C H THE RO C K W A LL W ITH 5/ 16 X 1-1/ 2" HEX BO LTS A ND 5/ 16" WASHERS.
4: W HEN THE 90
BRA C KETS A RE SEC URE, A ND THE RO C K W A LL IS IN ITS FINA L PO SITIO N; TIG HTEN THE
5/ 16 X 1-1/ 2" BO LTS O N THE RO C K W A LL SIDES.
T-NUT
G REEN BRAC KET
5/ 16" WASHER
5/ 16" X 1-1/ 2" HEX BO LT
90
2 X 4 X 36"
PA NEL BO A RD
SC A LE 1 : 8
DETA IL A
2 X 4 X 36"
PA NEL BO A RD
3
4
"
A
51
