DETA IL A
SC A LE 1 : 7
5/ 16" X 2-1/ 2" HEX BO LT
5/ 16" WASHER
T-NUT
(INSTA LL FIRST)
2-1/ 2" W O O D SC REW
DETA IL B
SC A LE 2 : 15
3" W O O D SC REW
A
2 x 4 x 33-1/ 8"
FO RT SIDE
SUPPO RT
B
STEP 10: A TTA C HING FO RT SIDE SUPPO RTS
1: LA Y THE 2 X 4 X 33-1/ 8"" FO RT SIDE SUPPO RTS O N A FLA T SURFA C E WITH THE A NG LED ENDS
O RIENTED THE WA Y THEY WILL BE INSTA LLED O NTO THE FO RT. PLAC E A T-NUT IN THE PRE-DRILLED
HO LE O N EA C H END A ND SEC URE W ITH HA MMER.
2: THE 2 X 4 X 33-1/ 8" FO RT SIDE SUPPO RTS (W ITH A NG LED ENDS) ATTA C H TO THE HO LES O N THE
ENDS O F THE 2 X 6 X 75" END SA NDBO X BO ARD O N THE INSIDE WITH 2-1/ 2" HEX BO LTS A ND
5/ 16" W A SHERS. THE A NG LED ENDS SHO ULD REST FLUSH A G A INST THE C O RNER PO STS. SEE
DETA IL A FO R C LA RIFIC A TIO N IF NEC ESSA RY.
3: ENSURE THA T THE TW O FO RT SIDE SUPPO RTS ARE A TTA C HED PRO PERLY TO THE SA NDBO X
BO A RD BEFO RE SEC URING THEM TO THE C O RNER PO STS. USE A 2-1/ 2" WO O D SC REW IN THE
TO P HO LE O F THE SUPPO RT, THEN USE A 3" W O O D SC REW IN THE BO TTO M HO LE O F THE
SUPPO RT. SEE DETAIL B FO R C LA RIFIC A TIO N IF NEC ESSA RY.
