Gorilla Playsets Playmaker - 2400 - STEP 31

REA R PA NEL (A )
2" W O O D SC REW
SWING BEA M PA NEL (B)
5/ 4 X 6 X 28"
PANEL SLAT (4 O N REAR, 4 O N LEFT SIDE)
FRO NT PA NEL SLA T SPA C ING
ALL THE SLATS O N THE FRO NT
MUST BE RESTING O N THE
DEC K. A LL FO UR FRO NT SLA TS
ARE 26-3/ 4" LO NG .
MA KE THIS SLAT FLUSH TO THE
END O F THE 2 X 4 X 14"
BO TTO M PA NEL BO A RD.
SPA C E THE NEXT SLAT
EQ UA LLY BETWEEN THE FIRST
SLAT AND THE C O RNER PO ST.
5/ 4 X 6 X 26-3/ 4"
PANEL SLAT (4 O N FRO NT)
STEP 31: PANEL SLATS
1: FIND EIG HT 5/ 4 X 6 X 28" PA NEL SLA TS AND FO UR 5/ 4 X 6 X 26-3/ 4" PA NEL SLATS.
2: INSTA LL THE PANEL SLA TS AS SHO WN BELO W. SEE DETA ILS BELO W FO R MEASUREMENTS.
3: A TTA C H THE PANEL SLA TS TO THE FO RT WITH 2" WO O D SC REW S IN THE PRE-DRILLED HO LES.
SPA C ING
2"
1
1
2
"
2"
REA R PA NEL SLA T SPA C ING (A ) SWING BEA M PA NEL (B)
1
12"
4
" 2"
2"
2
1
4
2"
58
