Gorilla Playsets Playmaker - 2400 - STEP 32

HEX BO LT
5/ 16" WASHER
T-NUT
DETA IL A
5/ 16" X 2-1/ 2"
2-1/ 2" W O O D SC REW
A
STEP 32: A TTA C HING C ENTER PO STS
BO LT, A 5/ 16" W A SHER A ND A T-NUT.
1: THE 2 X 4 X 25" C ENTER PO STS W ILL SEC URE TO THE TA RP SUPPO RTS WITH A 5/ 16" X 2-1/ 2" HEX
NO TE: MAKE SURE THE 2 X 4 X 25" C ENTER PO STS A RE VERTIC A L.
2: FA STEN EA C H C ENTER PO ST TO THE TA RP SUPPO RT W ITH TW O 2-1/ 2" WO O D SC REW S.
2 X 4 X 25"
TA RP C ENTER PO ST
59
