C O RNER
PO ST
FRO NT
SWING BEAM
SUPPO RT
THIS STEP WILL REQ UIRE YO U TO C LIMB O NTO THE DEC K. YO U WILL NEED TO INSTA LL THE BO A RDS O N THE INSIDE
O F THE TA RP SUPPO RT AND A RC H FA C E BO A RD.
1: PLAC E A 1 X 5 X 19-1/ 4" WALL PANEL BO A RD 2 3/ 16" A WA Y FRO M EA C H O F THE FRO NT C O RNER PO STS.
ATTA C H EAC H BO A RD WITH # 8 X 1-1/ 2" W O O D SC REW S.
2: PLAC E A 1 X 4 X 11" WALL PANEL BO A RD 3 FLUSH TO THE SIDE O F WA LL PA NEL BO A RD 2. SPAC E WALL PANEL
BO ARD 3 1-3/ 16" DO W N FRO M THE TO P O F THE TARP SUPPO RT. ATTA C H THE BO A RD WITH # 8 X 1-1/ 2" W O O D
SC REWS. REPEAT FO R THE O THER WALL PA NEL BO A RD 3 O N THE O THER SIDE.
3: PLAC E A 1 X 4 X 19" WALL PANEL BO A RD1 FLUSH TO THE SIDE O F WA LL PA NEL BO A RD 3. SPAC E WALL PANEL
BO ARD 1 2" DO W N FRO M THE TO P O F THE TA RP SUPPO RT. A TTA C H THE BO A RD WITH # 8 X 1-1/ 2" W O O D
SC REWS. REPEAT FO R THE O THER WALL PA NEL BO A RD O N THE O THER SIDE.
4: PLAC E THE 1 X 4 X 9" C O NNEC TO R BO ARD C ENTERED UNDER THE TARP C ENTER PO ST. THE MIDDLE 2 HO LES
SHO ULD BE A T THE TO P. FA STEN THE C O NNEC TO R BO ARD TO THE WA LL PA NEL BO A RD 1 BO ARDS WITH
FO UR # 8 X 1-1/ 4" W O O D SC REWS.
5: SLIDE THE 1 X 4 X 19" C ENTER W ALL PA NEL BO A RD UNDER THE C O NNEC TO R BO ARD. THE HO LES IN THE C ENTER
WA LL PA NEL BO A RD SHO ULD BE O N THE BO TTO M. FASTEN THE C ENTER WALL PA NEL BO A RD TO THE C O NNEC TO R
BO ARD WITH TWO # 8 X 1-1/ 4" W O O D SC REWS. FASTEN THE C ENTER W ALL PA NEL BO A RD A T THE BO TTO M TO THE
ARC H FA C E BO A RD WITH # 8 X 1-1/ 2" W O O D SC REW S.
STEP 32A : WINDO W SLATS
TA RP C ENTER PO ST
INSIDE VIEW
"
"
16
3
1
3
16
2"
1 X 4 X 19"
C ENTER WALL
PANEL BO A RD
1-4-1900-C WPB
(HA S 2 HO LES IN IT)
1 X 4 X 9"
C O NNEC TO R BO A RD
1-4-0900-C B
1 X 4 X 19"
WA LL PA NEL BO A RD 1
1-4-1900-WPB1
(HA S 4 HO LES IN IT)
1 X 4 X 11"
WA LL PA NEL BO A RD 3
1-4-1100-WPB3
1 X 5 X 19-1/ 4"
WA LL PA NEL BO A RD 2
1-5-1925-WPB2
# 8 X 1-1/ 2"
WO O D
SC REW
# 8 X 1-1/ 4"
WO O D
SC REWS
TA RP SUPPO RT
FRO NT
C O RNER
PO ST
ARC H FA C E BO A RD
SWING BEAM
SUPPO RT
60
