11 Specifications
GAIN RANGE (Instrument Input to DI Output)
DI Output, Level: Line -2dB - 36dB
Amp Output 0dB-39dB
Boost 0dB-10dB
THD+N 22Hz-22kHz BW
1kHz @ 0dB Gain +10dBu out <0.0070%
1kHz @ 20dB Gain +10dBu out <0.0045%
1kHz @ 36dB Gain +10dBu out <0.0080%
INTERMODULATION DISTORTION - SMPTE/DIN 4:1 7kHz/50Hz
@ 40dB Gain +10dBu out <0.05%
FREQUENCY RESPONSE
Inst input @ 20dB Gain -3dB 20Hz – 65kHz
I/O IMPEDANCE
Instrument Input HI: 10MΩ / MED: 1MΩ / LOW: 330kΩ
Insert Input 10kΩ
Insert Output, No Pad 750Ω
Insert Output, -6dB Pad 375Ω
Insert Output, -16dB Pad 122Ω
DI Output 150Ω
Amp Output 150Ω
Tuner Output 150Ω
SIGNAL / PEAK LED METER
Green threshold -16dBu
Red threshold +8dBu
MAXIMUM INPUT LEVEL
Instrument Input +20dBu
Insert Return (0dB Boost) +20dBu
MAXIMUM OUTPUT LEVEL - 100k Ohm load, 0.1% THD
DI Output (Line) +19dBu
DI Output (Mic) -7dBu
Amp, Tuner, Insert Outputs +21dBu
Insert Output, No Pad +21dBu
Insert Output, -6dB Pad +15dBu
Insert Output, -16dB Pad +5dBu
HIGH PASS FILTER / NOTCH FILTER
High Pass Filter 20Hz – 1kHz @ -12dB/octave
Notch Filter 20Hz – 1kHz, >-35dB, Q>1.0
EQ
Gain +/- 12dB
Low Frequency Low Range: 125Hz Shelving / High Range: 250Hz Shelving
Mid Frequency Low Range: 70Hz – 880Hz / High Range: 670Hz – 8kHz
Mid Frequency Q 0.5 – 5
High Frequency 2kHz Shelving
DYNAMIC RANGE 22Hz-22kHz BW
Minimum Gain, DI Out 118dB
OUTPUT NOISE 22Hz-22kHz BW
Minimum Gain, DI Output -99dBu
Minimum Gain, Amp Out -96dBu
Maximun Gain, DI Out -77dBu
Maximum Gain, Amo Out -74dBu
POWER CONSUMPTION
100-240VAC 50/60Hz 10 Watts Max
POWER OUTPUT
2.1mm BOSS™ style power jack, center negative 9VDC, 500mA Max
WEIGHT and DIMENSIONS
2.2lbs (1kg) H3.0” x W6.2” x D5.5” (H7.6cm x W15.7cm x D14.0cm)
