Grace ALiX - Top Panel Controls and Features

4
5 Top Panel Controls and Features
1 2 3 4
9 11 12
5 6
7 8
10
1. Signal / clip LED indicator
2. Gain control
3. High Pass / Notch lter frequency select
4. Parametric Midrange cut and boost
5. Parametric Midrange frequency select
6. Parametric Midrange Q factor
7. BOOST footswitch
8. Low frequency shelving cut and boost
9. High frequency shelving cut and boost
10. Boost level
11. MUTE / TUNE footswitch
12. Amp / Tuner output level
