Grace GMQ Pro - Take Up Sides Assembly; Take Up Sides to Table Assembly

18
(ID: 040708)
1/4" X 1-1/2"
Carriage Bolt
3/16" Flat Washer
1/4" Jam Nut
1/4" Jam Nut
3/16" Flat Washer
1/4" X 1-1/2"
Carriage Bolt
Left Take Up
Side Assembly
1/4" Plastic Knob
1-1/4" Fender Washer
1/4" Plastic Knob
Right Take Up
Side Assembly
1-1/4" Fender Washer
Step 13: Take Up Sides Assembly
 
  
  
  
 
 


 





 


 




 

 



Step 14: Take Up Sides to Table Assembly
 
  
  
M6 Jam Nut
M5 Flat Washer
M6 x 40mm
Carriage Bolt
M5 Flat Washer
M6 Jam Nut
M6 x 40mm
Carriage Bolt
M8 Fender Washer
6MM Plastic Knob
M8 Fender Washer
6MM Plastic Knob
