20
(ID: 040708)
Left 3 Rail Side
1/4" Flat Washer
1/4" Nylock Nut
1/4" Plastic Knob
1-1/4" Fender
Washer
Right 3 Rail Side
1/4" Flat Washer
1/4" Nylock Nut
1-1/4" Fender
Washer
1/4" Plastic Knob
3/16" Flat Washer
1/4" Jam Nut
1/4" X 2-1/4"
Carriage Bolt
1/4" X 2-1/4"
Carriage Bolt
3/16" Flat Washer
1/4" Jam Nut
M6 Flat Washer
M6 Nylock Nut
M8 Fender
Washer
6MM Plastic Knob
M6 Nylock Nut
M6 Flat Washer
M8 Fender
Washer
M6 Plastic
Knob
Step 17: Three Rail Side to Table Assembly
Step 18: Pivot End to Fabric Layer Rail Mount End
M6 Jam Nut
M5 Flat Washer
M6 x 55mm
Carriage Bolt
M6 Jam Nut
M5 Flat Washer
M6 x 55mm
Carriage Bolt
To Next Page
