(ID: 040708)
Right Fabric Layers Rail
Mount End Assembly
1-1/4" Fender Washer
1/4" Plastic Knob
1/4" Flat Washer
1/4" Nylock Nut
Left Fabric Layers Rail
Mount End Assembly
1/4" Plastic Knob
1-1/4" Fender Washer
1/4" Nylock Nut
1/4" Flat Washer
1/4" X 1-1/2"
Carriage Bolt
3/16" Flat Washer
1/4" Jam Nut
1/4" X 1-1/2"
Carrriage Bolt
3/16" Flat Washer
1/4" Jam Nut
Step 19: Pivot End/ Fabric Layer Rail Mount End to Table Assembly
Step 20: Batting Rail Mount End
M6 x 40mm
Carriage Bolt
M6 Nylock Nut
M6 Flat Washer
6MM Plastic Knob
M8 Fender Washer
M5 Flat Washer
M6 Jam Nut
M6 x 40mm
Carriage Bolt
M5 Flat Washer
M6 Jam Nut
M8 Fender Washer
6MM Plastic Knob
M6 Nylock Nut
M6 Flat Washer
To Next Page
