24
(ID: 040708)
Coupler
King Size Rail
70” Rail
34” Rail
24” Rail
End Cap Shoulder
#8 x 1-1/8” Screw
Step 23: Rails to Frame Assembly
**To make it easier to put your rails in you could loosen both knobs on your Left and Right Take Up Sides.
This will allow you to move your Take Up Sides away from your frame slightly, making it easier to insert your
rails on your frame.
Note:
M4 x 20mm screw
