Grace GMQ Pro - Take Up Rail Mount End Assembly; Take Up End to Table Assembly

19
(ID: 040708)
1/4" X 1-1/2"
Carriage Bolt
3/16" Flat
Washer
1/4" Jam
Nut
1/4" X 1-1/2"
Carriage Bolt
1/4" Jam Nut
3/16" Flat Washer
Right Take Up
Rail Mount End
1/4" Plastic Knob
1-1/4" Fender Washer
1/4" Nylock Nut
1/4" Flat Washer
Left Take Up Rail
Mount End Assembly
1-1/4" Fender Washer
1/4" Plastic Knob
1/4" Nylock Nut
1/4" Flat Washer
M6 Jam Nut
Step 15: Take Up Rail Mount End Assembly
 
  
  
  
 



 


 

Step 16: Take Up End to Table Assembly

  
  
  
  



 



 


M5 Flat
Washer
M6 Jam
Nut
M6 x 40mm
Carriage Bolt
M6 x 40mm
Carriage Bolt
M5 Flat Washer
M6 Flat Washer
M6 Nylock Nut
6MM Plastic
Knob
M8 Fender Washer
M8 Fender Washer
6MM Plastic Knob
M6 Nylock Nut
M6 Flat Washer
