Setup
3A7031A 15
Program Settings
Feature Description
Modes of Operation Maximum/Minimum
and Additional Comments
Interval, page 12
Mode Timer Machine Count
Machine Count 1 to 10,000
Machine Count Options
- Action to start lubrication or alarm when timeout
expires
- Enable a backup timeout
Interval HH:MM (00:01 to 99:59)
Defines time between lubrication events
End On, page 13
Mode Timer, Pressure Switch, Pressure Sensor, Cycle
Timeout HH:MM:SS (00:00:10 to 03:00:00)
Pressure Type 0-5V, 0-10V, 1-5V, 4-20mA
Pressure Sensor Units PSI, kPa, bar, %
Pressure Sensor Full Scale 1 to 20,000
Requires: Threshold is less than or equal to Full Scale
Pressure Sensor Threshold 1 to 20,000
Requires: Threshold is less than or equal to Full Scale
Pressure Sensor Target 1 to 20,000
Requires: Threshold is less than or equal to Full Scale
Cycles 0 to 100
Cycle Option Solenoid Alarm Enables alarm when cycles are detected during idle time
Low Level, page 13
Low Level Type Paddle, Low Level Switch, Low Level Sensor
Paddle Low Level Alert
Threshold
Recommended: 10
00 to 99
Requires Alarm > Alert
Setting of zero disables low level alert threshold
Paddle Low Level Alarm
Threshold
Recommend: 80
00 to 99
Requires: Alarm > Alert
Setting of zero disables low level alarm threshold
Paddle Alarm Auto-Clear Enables a feature that will automatically clear a low level
alarm and start a lubrication event to check if the reservoir is
still empty
Level Switch Type Sets low level behavior as low level Alert or low level alarm
Sensor Type 0-5V, 0-10V, 1-5V, 4-20mA
Sensor Alert Threshold 0 - 100
Requires: Alarm < Alert
Setting of zero disables low level alert threshold
Sensor Alarm Threshold 0 - 100
Requires: Alarm < Alert
Setting of zero disables low level alarm threshold
Start Up, page 14 Delay Time MM:SS (00:01 to 59:59)
Output 2, page 14
Output Type Activated pm Alarm, only, Alert only, Alarm and Alerts, or to
close Vent Valve
System, page 14
Date Month: 1 - 12
Day: 1 - 31
Year: 18 - 99
Time 00:00:00 to 23:59:59
24-hour time
