Technical Specifications
24 3A7031A
Technical Specifications
All trademarks or registered trademarks are the property of their respective owners.
*Total current from all outputs maximum is 15 A.
GLC X Controller
US Metric
Climate
Operating Temperature Range -22 F° to 158 F° -30 C° to 70 C°
Storage Temperature -22 F° to 158 F° -30 C° to 70 C°
Maximum Humidity 90% RH (non-condensing)
Materials of Constructions
Enclosure Material ABS
Membrane Material Polyester
Lens Material Polycarbonate
Input Contact
Power Source DC
9 - 30 VDC
Power Consumption
1 W (no load), 15 A (max)
Outputs*
Pump Control
Max Switching Voltage 30 VDC
Max Switching Current 10 A
Auxiliary
Max Switching Voltage 30 VDC
Max Switching Current 10 A
Inputs 1 and 2
Maximum Analog Voltage Input 10 V
Inputs 3 and 4
Maximum input rate 300 rpm
Noise (dBa)
Maximum sound pressure
Less than 70 dB
Miscellaneous Data
IP Rating IP69K
Bluetooth LE 1 mW
Altitude <2000m
