Typical Installation
6 3A7031A
Typical Installation
The installation shown in FIG. 3 is only a guide for selecting and installing system components.
Key:
A Lubrication Controller
B Solenoid Value
C Pump Module
D Ignition Switch
E High Pressure Lubricant Supply Lines
F Injector Banks
G In-line 15A Fuse
H Power Source
J Pressure Sensor
K Level Sensor
FIG. 3: Typical Installation
H
D
G
A
F
E
C
B
J
K
