Graco A Series Instructions

Parts
22 309577T
‡ Parts included in Kit 249770 (purchase separately).
* Parts included in Pump Repair Kits (purchase
separately). Some parts in the kit may not be used in
your pump.
† Parts included in Wet-Cup Kits. Order the correct kit for
your pump from the table below. See page 30 for
information on 246928 Reservoir Kit.
16* 105444 BALL, piston; sst; 0.3125 in. (8 mm) 1 1
101947 BALL, piston; sst; 0.375 in. (10 mm) 11
107203 BALL, piston; sst; 0.5625 in. (14 mm) 1
17* 15B075 BUSHING, rod 1 1
15B074 BUSHING, rod 11
15B076 BUSHING, rod 1
18* 15J196 BUSHING, pump 1 1
17F957 BUSHING, pump 1
19† 15C569 NUT, packing 1 1
15C571 NUT, packing 11
15C573 NUT, packing 1
20* 117447 SEAL, u-cup, throat; UHMWPE 1 1
117446 SEAL, u-cup, throat; UHMWPE 11
117448 SEAL, u-cup, throat; UHMWPE 1
22*† 118377 RING, retaining 1 1
118378 RING, retaining 11
118379 RING, retaining 1
23* 15B661 TOOL, installation, seal; not shown; part of Repair Kit
246420
1
24*† 118381 O-RING; fluoroelastomer 1 1
107563 O-RING; fluoroelastomer 11
118403 O-RING; fluoroelastomer 1
25† 118374 SPRING 1 1
118375 SPRING 11
118376 SPRING 1
26*† 118380 O-RING; fluoroelastomer 1 1
110955 O-RING; fluoroelastomer 11
C20111 O-RING; fluoroelastomer 1
27*† 107563 O-RING; fluoroelastomer 1 1
103414 O-RING; fluoroelastomer 11
111178 O-RING; fluoroelastomer 1
28† 15C570 PISTON, wet-cup, ISO 1 1
15C572 PISTON, wet-cup, ISO 11
15C574 PISTON, wet-cup, ISO 1
Ref. Part Description
Qty.
246830 246831 262647 246832 24Y175
Pump Part Pump Repair Kit Wet-Cup Kit
246830 246420 246962
246831, 262647 15C851 246963
246832 15C852 246964
24Y175 17K351 246962
