Parts
309577T 27
‡ Parts included in Kit 249770 (purchase separately).
† Wet-Cup Conversion Kits may be purchased
separately to convert pumps 245970, 245971, 262648,
and 245972. See page 30 for further information.
* Parts included in Pump Repair Kits (purchase
separately). Some parts in the kit may not be used in
your pump. Order the correct kit for your pump from the
table below.
16* 105444 BALL, piston; sst; 0.3125 in. (8 mm) 1 1
101947 BALL, piston; sst; 0.375 in. (10 mm) 11
107203 BALL, piston; sst; 0.5625 in. (14 mm) 1
17* 15B075 BUSHING, rod 1 1
15B074 BUSHING, rod 11
15B076 BUSHING, rod 1
18* 15J196 BUSHING, pump 11
17F957 BUSHING, pump 1
19† 193046 NUT, packing 1 1
193032 NUT, packing 11
189589 NUT, packing 1
20* 117447 SEAL, u-cup, throat; UHMWPE 1 1
117446 SEAL, u-cup, throat; UHMWPE 11
117448 SEAL, u-cup, throat; UHMWPE 1
21* 117597 WASHER, felt 2 2
117599 WASHER, felt 22
117600 WASHER, felt 2
22* 551528 RING, retaining 1 1
117718 RING, retaining 11
117719 RING, retaining 1
23* 15B661 TOOL, installation, seal; not shown; part of Repair
Kit 246420
1 1
Ref. Part Description
Qty.
245970 245971 262648 245972 24Y174
Pump Part Repair Kit
245970 246420
245971, 262648 246421
245972 246422
24Y174 17K352
