Technical Data
Technical Data
Mix Manifold U.S.
Metric
Maximum fluid working
pressure:
24R991 Low Pr
essure
Mix Manifold
300 psi 2.1 MPa, 21 ba
r
24R992 High Pressure
Mix Manifold
1500 psi 10.5 MPa, 105 bar
24T273 High Pressure
Mix Manifold, for
acid-catalyzed materials
1500 psi 10.5 MPa, 105 bar
Mixing rat
io range:
0.1:1 — 50:1, ±1%
Fluid outlet size (static
mixer):
3/8 npt(f)
Weight (approximate):
1.25 lb 0.57 kg
Wetted p
arts:
16W556
Mix Manifold
302, 30
3, 316, and 17–4PH SST,
perfluoroelastomer; PEEK, PTFE, CV-75
16W616 Mix Manifold, for
acid-catalyzed materials
302, 316, and 17–4PH SST,
perfluoroelastomer; PEEK, PTFE, CV-75
3A2801A
11
