Accessories
Accessories
Part No. Description
24N641
1/8 in. (3 mm) I
D Fluid Whip Hose; nylon; 6 ft (1.8 m); for high and low pressure applications.
3200 psi (22 MP
a, 220 bar) Maximum Fluid Working Pressure.
24N305
1/4 in. (6 mm) ID Fluid Whip Hose; nylon; 6 ft (1.8 m); for low pressure applications only. 225
psi (1.6 MPa, 16 bar) Maximum Fluid Working Pressure.
24N348
1/4 in. (6 mm) ID Fluid Whip Hose; ptfe; 6 ft (1.8 m); for high pressure applications only. 3000
psi (20.7 MPa, 207 bar) Maximum Fluid Working Pressure.
24T753
Acid Catal
yst Conversion Kit. To convert a 16W556 standard mix manifold to a 16W616 mix
manifold f
or use with acid-catalyzed materials.
24T873
Fluid Outlet Quick Disconnect Kit. Replaces the manifold’s fluid outlet fitting to allow
quick-disconnect of the static mixer hose.
24U059
5/16 in. (8 mm) ID Grounded Air Whip Hose, for use with electrostatic guns; 1/4 npsm(f) x
1/4 npsm (f) left–hand thread; 6 ft (1.8 m). 100 psi (0.7 MPa, 7 bar) Maximum Air Working
Pressure.
16F537
5/16 in
. (8 mm) ID Air Whip Hose, for use with conventional air spray guns; 1/4 npsm(f); 6 ft
(1.8 m)
. 200 psi (1.4 MPa, 14 bar) Maximum Air Working Pressure.
24S004 Air Line Quick Disconnect, for use with electrostatic guns.
10 3A2801A
