Parts
Mix Manifold P
arts
Part No. 16W556 Mix Manifold (used on 24R991 and 24R992 Kits)
Part No. 16W61
6 Mix Manifold (used on 24T273 Kit for acid-catalyzed materials)
Ref.
No.
Part
No.
Description
Qty
1
———
BODY
, manifold
1
2◆
———
O-RING; PTFE
1
3◆
———
WASHER, backup; acetal
2
4 178745
STE
M, valve, ball
1
5
165964 NUT, packing 1
6‡
———
BALL, stem 1
7‡
———
PLUG, ball valve
1
Ref.
No.
Part
No.
Description
Qty
8†‡
———
BEARING, guide; acetal
1
9†‡ 111457
O-RING; PTFE
1
10‡
———
NOZZLE, mix
1
11 16W554
FITTING, outlet; 3/8 npsm(m)
1
12*‡
———
SEAT, ball; PEEK
3
13*‡
112319
O-RING; chemically resistant
3
14*‡
121399
O-RING; chemically resistant
6
16W551
PLUG; for 16W556
315
24T874
PLUG; f
or 16W616
3
16 24T838 LEVER 1
17 102310 NUT, hex; 10–32 1
18
———
HANDL
E, lever
1
16W462
VALVE, check; 1/4 npsm; for
16W556
219
16W461
VALVE, check; 1/4 npsm; for
16W616
2
20 16W4
63
VALV
E, check; 3/8 npsm
1
22*‡
———
SEAL, ball; PPS
3
23 112506
SCREW, ground; 4–40 x 0.25
in. (6 mm)
1
* These parts are included in Plug Seals Repair Kit
420011, which must be ordered separately.
◆T
hese parts are included in Lever Seals Repair Kit
42
0012, which must be ordered separately.
† These parts are included in Outlet Seals Repair Kit
420013, which must be ordered separately.
‡ These parts are included in Ball Repair Kit 24T752,
which must be ordered separately.
Parts labeled — — — are not available separately.
3A2801A 9
