General Information
The Series 700 Turbine Spray Gun can spray most
coatings or finishes currently being used for automo-
tive refinish, industrial, aerospace, marine, wood,
plastic and architectural applications.
This spray
gun
typically utilizes
5
psi (0.34 bar) for
CX-7 and CX-8 and
6
psi (0.41 bar) for the CX-9
inbound air pressure to produce high quality paint
finishes. The gun produces a cone of air that carries
and directs the paint from the gun to the surface,
ciency. This enables painters to comply with new
minimizing overspray and increasing transfer effi-
clean air laws that are designed to reduce VOC (vola-
tile organic compounds) emissions, eases paint
application by requiring fewer paint passes to obtain
time.
coverage, and saves on both material and clean-up
0
1 Gun Instruction Manual, 308-336
The contents
of
the CX-8 Turbine Sprayer, Model
M70122, includes:
0
1 CX-8 Turbine Sprayer, M72782
1
Turbine Gun, M70361
1
20
ft.
hose, M71580
0
1 2 qt. cup, M70962
1
20 ft. braided air hose, M71588
0
10 wire ties, M71179
1 male, quick disconnect, M70675
1 Sprayer Instruction Manual, 308-422
0
1
Gun Instruction Manual, 308-336
The contents
of
the CX-8 bare sprayer, Model
M71282, includes:
Refer to the turbine gun manual, 308-336, for more
information on the operation and use of the turbine
1 CX-8 Turbine Sprayer, M72782
1 Sprayer Instruction Manual, 308-,422
spray gun.
The contents
of
the CX-9 Turbine Sprayer, Model
Unpack the Graco Turbine Sprayer from the shipping
M70136, includes:
carton and inspect for any possible shipping damage.
1
CX-9 Turbine Sprayer, M72783
If necessary, call the Graco Customer Service toll-
free number at 800-328-021 1.
1 20ft. hose. M71580
0
1 Turbine Gun, M70308
The contents
of
the CX-7 Turbine Sprayer, Model
1 Sprayer Instruction Manual, 308-422
M70102, includes:
0
1 Gun Instruction Manual, 308-336
1 CX-7 Turbine Sprayer, M72781
1
Turbine Gun, M70308
1 20
ft.
hose, M71580 1 CX-9 Turbine Sprayer, M72783
1 Sprayer Instruction Manual, 308-422
1
Sprayer Instruction Manual, 308-422
The contents
of
the CX-9 bare sprayer, Model
M71283, includes:
Specifications
Power Requirements
.;
......
110/12OVAC, 50/60 Hz
Amps
@
120
volts
CX-7
...................
1 phase,
8
amp minimum
CX-8, CX-9
............
1 phase, 10 amp minimum
Power Cord
........
No.
16 AWG. 3 wire,
10
ft (3 m)t
CFM unrestricted (3/4" restriction)
CX-7, CX-8
............................
97 CFM
CX-9..
................................
105 CFM
Turbine Stages
.................................
2
Maximum Turbine Hose Length
CX-7, CX-8
.........................
40ft (12 m)
CX-9
................................
60
ft (18 m)
CUP
cx-7,
cx-9
................................
1 qt
cx-8..
.....................................
2 qt
...
t
DO
NOT
exceed
100
n,
12
AWG
extension cord
a
registered trademark of the
Du
Pont Corporation.
Wetted Parts
Bare Spray Gun
.........
Stainless Steel,
Hard-coated Aluminum,
Spray Gun Cups
........
Aluminum, Polyethylene
2
Quart Accessory
Remote Pressure Pot.
...
Aluminum, Polyethylene
2-112 Gallon Accessory
Remote Pressure Pot
..........
Galvanized Steel,
EPDM (standard)
4 308-422
