Graco D Series User Manual

Know Your Sprayer
10 3A3234E
Stand Models (SP200/2400 Series D)
A
B
D
U
ti31597a
E
T
Q
F
N
P
C
W
G
H
J
K
M
L
A PushPrime™ Button
B Prime/Spray Valve
C Pressure Control Knob
D ON/OFF Switch
E Suction Tube
F Drain Tube (with diffuser)
G Airless Spray Gun
H Reversible Spray Tip
J Tip Guard
K Gun Trigger Lock
L Gun Fluid Inlet Fitting
M Gun Fluid Filter (inside handle)
NPump
P Pump Fluid Outlet Fitting (airless hose
connection)
Q Airless Hose
T Inlet Strainer
U Power Cord
W Suction Tube Drip Cup
Model/Serial Tag (Not shown, located
on bottom of unit.)
See Quick Reference, page 24 for more
information.

Graco D Series Specifications

General

Brand	Graco
Model	D Series
Category	Paint Sprayer
Language	English
