Quick Reference
Page 8 Name Description
A Prime/Spray Valve • In PRIME position directs fluid to drain tube.
• In SPRAY position directs pressurized fluid to
paint hose.
• Automatically relieves system pressure in over-
pressure situations.
B PushPrime Button Taps the inlet ball when pushed to loosen it.
C Pressure Control Knob Increases (clockwise) and decreases
(counter-clockwise) fluid pressure in pump, hose,
and spray gun. To select function, align symbol on
pressure control knob with setting indicator, page
12.
D ON/OFF Switch Turns sprayer ON and OFF.
E Suction Tube/Hopper Draws fluid from paint pail into pump.
F Drain Tube Drains fluid in system during priming and pressure
relief.
G Airless Spray Gun Dispenses fluid.
H Reversible Spray Tip
• Atomizes fluid being sprayed, forms spray pattern
and controls fluid flow according to hole size.
• Reverse position unclogs plugged tips without
disassembly.
J Tip Guard Reduces risk of fluid injection injury.
K Gun Trigger Lock (page 11) Prevents accidental triggering of spray gun.
L Gun Fluid Inlet Fitting Threaded connection for airless hose.
M Gun Fluid Filter Filters fluid entering spray gun to reduce tip clogs.
N ProXChange Pump Pumps and pressurizes fluid and delivers it to paint
hose.
P Pump Fluid Outlet Fitting Threaded connection for airless hose.
Q Airless Hose Transports high-pressure fluid from pump to spray
gun.
R InstaClean
™
Fluid Filter • Filters fluid coming out of pump to reduce tip plug-
ging and improve
finish.
• Self cleans only during pressure relief.
S Pail Hanger For transporting pail by its handle.
T Inlet Strainer Prevents debris from entering pump.
U Power Cord Plugs into power source.
V Easy Access Door Easy Access Door permits quick access to the
pump. Open pump door by pulling out on the tabs
while sliding door away from the pump inlet.
W Suction/Drain Tube Cup Holds suction and drain hoses.
X Pump Removal Tool Use cut out in the frame to remove/install pump
packing.
Z Inlet Valve Removal Tool Cut out in the frame provide the tools to quickly
remove/install the inlet valve without additional tools.
Power Flush Attachment Connects garden hose to suction tube for power
flushing water-based fluids.
