Part 246775, 225 Mini-Fire-Ball Pump Parts
309869C 39
Part 246775, 225 Mini-Fire-Ball Pump Parts
Ref.
No. Part No. Description
Qty.
6 100400 BALL, metallic 1
7 100078 SCREW, thread forming, hex head 12
8 100279 BALL, metallic 1
9 101578 SCREW, cap, hex head 6
10 118718 SCREW, machine 2
11* 107227 PACKING, o-ring 1
12* 107306 PACKING, o-ring 1
13* 113347 PACKING, o-ring 1
15 156698 PACKING, o-ring 1
16* 118106 PACKING, block 1
17* 118107 GROMMET, lower valve 2
18* 118108 PACKING, o-ring 1
19 118109 PACKING, square 1
20 118111 SPRING, compression, helical 1
21* 157195 PACKING, o-ring 1
23 15C245 YOKE, rod, trip 1
24* 15C246 NUT, valve 4
25* 15C247
WIRE, lock
2
26 15C248 CLIP, spring 2
27 15C249 ACUTATOR, valve 1
28 253580 BASE, motor, air (includes 28a) 1
28a 116343 SCREW, grounding 1
29 15C252 ROD, displacement, mp 1
30 15C266 GASKET, copper 1
31* 15C267 POPPET, valve 2
32* 248211 VALVE, poppet** 2
34 15C270 PISTON, motor, air 2-1/4” 1
35 15C274 CYLINDER, motor, air 1
36 15C275 PIN, toggle 2
37 15C276 PIN, pivot 2
38 15C277 ARM, toggle 2
39 15C278 NUT, cap, cylinder 1
40 15C279 ROD, trip 1
41 15C499 CYLINDER, fluid 1
42 15C500 HOUSING, valve 1
43 15C501 PISTON, fluid 1
44 15C533 RETAINER, ball 1
46 246782 PLATE, muffler, serial number 1
47 246783 PLATE, muffler, warning 1
* Included in pump Repair Kit 246918
**Use gap adjustment tool 15E796 (also included in
Repair Kit 246918) to ensure correct gap setting for
poppets.
Ref.
No. Part No. Description
Qty.
