Graco Fire-Ball 246775 - Part 237526, 425 (3:1) Pump Parts List

Part 237526, 425 (3:1) Pump Parts List
309869C 41
Part 237526, 425 (3:1) Pump Parts List
Ref.
No. Part No. Description
Qty.
6 101178 BALL, piston; metallic 1
8 108001 BALL, sst 1
9 101578 SCREW, cap, hex hd 8
10 102975 SCREW, rd hd mach; 6-32 x 1/4” 2
11† 112565 PACKING, u-cup 1
12† 166071 PACKING, o-ring 1
13* 158379 PACKING, o-ring 1
13S 189711 WASHER, piston 1
14 116343 SCREW, grounding 1
15 156698 PACKING, o-ring 1
16† 112130 SEAL, pump 1
17* 158367 GROMMET, inlet valve 2
18* 158378 PACKING, o-ring 1
19 158377 PACKING, ring, seal 1
20 167585 SPRING, helical compression 2
21† 110828 PACKING, o-ring 1
23 158360 YOKE, rod, trip 1
23S 102656 MUFFLER, air exhaust 1
24* 160261 NUT, valve 4
25* 160618 WIRE, lock 2
26 158361 CLIP, spring 2
27 158359 ACTUATOR, valve, air 2
28 190229 BASE, air motor 1
29 190233 ROD, piston 1
31* 170709 POPPET, exhaust valve** 2
32* 236079 VALVE, poppet 2
34 207391 PISTON 1
35 162629 CYLINDER, motor, air 1
36 158362 PIN, toggle 2
37 158364 PIN, pivot 2
38 160623 ARM, toggle 2
39 190929 LIFT RING 1
40 207150 ROD, trip 1
41 189708 CYLINDER, pump 1
42 189709 VALVE HOUSING, 1 1/2 npt(f) 1
43 189707 PISTON/SEAT, valve 1
44 189710 RETAINER, ball 1
* Included in air motor repair kit 207385
** Use gap adjustment tool 171818 to ensure
correct gap setting for poppets.
† Included in lower repair kit 237602
