Graco Fire-Ball 246775 - 425 (6:1) Technical Data; 425 (6:1) Performance Chart Flow

425 (6:1) Technical Data
309869C 47
425 (6:1) Technical Data
Fluid to air ratio .........................................................6:1
Cycles/gallon (cycles/liter) ..............................12.0 (3.2)
Fluid flow @80 cpm (gpm/lpm) ....................... 6.6 (25.3)
Pumping distance guideline ........ up to 500 ft. (152.5 m)
Maximum fluid pressure.......1100 psi (7.6 MPa, 76 bar)
Air motor effective diameter ............ 4.25 in. (107.9 mm)
Air operating range ....40-180 psi (0.28-1.2 MPa, 2.8-12
bar)
Approx. air consumption and fluid flow @100 psi air and
80 cpm .49.5 scfm @6.8 gpm (.334 m
3
/min @25.7 lpm)
Dry suction lift (feet of water)......................................23
Wetted materials . steel, polyurethane, aluminum, nitrile
Air inlet port size..........................................1/2 in. npt(f)
Fluid inlet port size ......................................1.5 in. npt(f)
Fluid outlet port size ....................................3/4 in. npt(f)
Sound pressure (measured 1 meter from unit) 80.85dB
Sound pressure (ISO 9614-2) .......................... 94.62dB
F
l
u
i
d
Ou
t
l
e
t
Pr
e
s
s
u
r
e
Test Fluid: No. 10 Weight Oil
6
(22.71)
425 (6:1) Performance Chart
