307-863
9
SETUP
4. Check
the engine oil level.
Refer to the Hon
-
da engine manual, supplied. This
is a summa
-
ry
of the information: Remove one of the oil fill
plugs; the oil should be almost overflowing.
See
Fig 9–1. Add oil as necessary
.
Recommended
lubrication oil:
Use a high–qu
-
ality, detergent oil, SAE 10W–40, classified
“FOR SERVICE SE or SF”, for regular use
and
for breaking–in a new engine.
5. Be
sure your system is properly grounded
before operating it. Read and follow the
warning section, FIRE OR EXPLOSION
HAZARD,
page 3.
6. Fill
the gas tank.
See the
FUELING
section,
below.
7. Flush
the pump
to remove the lightweight oil
which was left in the pump to protect it from
rust. Refer to the FLUSHING GUIDELINES,
page
12.
8. Prepare
the
paint
according to the manufac
-
turer’s recommendations. Remove any skin
that
may have
formed. Stir the paint to mix pig
-
ments.
9. Strain the paint through a fine nylon mesh
bag (available at most paint dealers) to re-
move particles that could clog the filter or
spray
tip. This is probably the most important
step
toward trouble–free spraying.
10. Keep the sprayer upright and level during
operation and whenever it is being moved.
Read
the last
CAUTION
on page 10.
FUELING
Gasoline
is extremely flammable and explosive un
-
der certain conditions. To reduce the risk of a fire
or
explosion:
Always shut of
f the engine before refueling.
Refuel in a well–ventilated area.
Do
not smoke or allow flames or
sparks in the
area
where
the engine is refueled or where the
gasoline
is stored.
Do
not overfill the tank. Make sure
the filler cap
is
securely closed after refueling.
Be careful not to spill fuel when fueling. Fuel
vapor or spilled fuel can ignite. If any fuel is
spilled,
make sure the area is dry before
start
-
ing
the engine.
WARNING
1. Fuel specifications. Use automotive gasoline with
a
pump octane number of 86 or higher
. If the engine
knocks or pings, use a higher octaine gasoline. Un-
leaded fuel minimizes combustion chamber
deposits.
2. Gasolines containing alcohol (gasohol). Do not
use
gasohol which contains methanol, if the gasohol
does
not contain cosolvents and corrosion inhibitors
for methanol. Even if it does contain such additives,
do not use the gasohol if it contains more than 5%
methanol.
NOTE: The HONDA engine warranty does not cover
damage
resulting from the use of gasolines con
-
taining alcohol. See the HONDA engine manual
for
more information.
3. General.
Do not use oil and gasoline mixtures or
con
-
taminated gasoline. Avoid getting dirt, dust or water
in
the fuel tank.
4. Tank
Capacity
.
0.66 gallons (2.5 liter). Always leave
at
least 1/2 in. at the top of the tank for expansion.
5. Shut off the engine before refueling.
6. After refueling, tighten the fuel tank cap firmly.
Fig 9–1
ENGINE
ON/OFF
SWITCH
OIL
FILL PLUG
GAS FILL CAP
GROUND WIRE
AND CLAMP
0141
0015
