18 308864
Parts List & Drawing -- Pinion Assembly
Ref No. 8 and 12
Ref No. 8: Pinion Housing Assembly 241 112 Ref No. 12: Drive Housing Assembly 241011
Ref
No. Part No. Description Qty
Ref
No. Part No. Description Qty
8 PINION HOUSING 1
8b 105489 PIN 2
8d* 193358 PINION SHAFT 1
8e* 112770 RETAINING RING, large 1
*Must be ordered separately
12 HOUSING, drive 1
12g* 194173 WASHER 1
12h* 194172 WASHER 1
*Must be ordered separately
To Next Page
