22 308549
Service
03275
04709B
04708
Fig. 13
1
3
4
2
24
104
403*
401*
24
24 104 401*
403*
105
19 402*
Cutaway View, with Diaphragms in Place Cutaway View, with Diaphragms Removed
1
Lips face out of housing (1).
Air Side must face center housing (1).
1
Grease.
Used on Models with PTFE diaphragms only.
1
1
105
3
3
2
2 4
2 4
23
5
Apply medium-strength (blue) LoctiteR or
equivalent. Torque to 20 to 25 ft-lb (27 to 34
NSm) at 100 rpm maximum.
5
5
To Next Page
