Graco Husky 1590 - Dimensions

308549 33
Dimensions
6.0 in.
(152.5 mm)
5.23 in.
(133 mm)
3.0 in.
(76 mm)
PUMP MOUNTING HOLE PATTERN
FRONT VIEW
SIDE VIEW
1/2 npt(f)
air inlet
3/4 npt(f)
air exhaust
outlet port I.D.:
1.75 in. (44.5 mm)
flange diameter:
5.5 in. (139.7 mm)
four 0.73 in.
(18.5 mm) slots
21.75 in.
(552.5 mm)
16.25 in.
(412.5 mm)
19.25 in.
(489 mm)
11.99 in.
(304.5 mm)
6.0 in.
(152.5 mm)
6.0 in.
(152.5 mm)
0.5 in.
(12.5 mm)
10 in.
(254 mm)
17.55 in.
(445.5 mm)
6.0 in.
(152.5
mm)
10.45 in.
(265.5 mm)
45_
7439B
inlet port I.D.:
1.75 in.
(44.5 mm)
four 0.73 in.
(18.5 mm) slots
