Tank Specifications and TLM Offset
3A9522A 21
Non-Standard Tanks:
• Maximum Volume = 999,999 gallons or
liters.
• The volume at various distances from
the TLM can be entered into the Pulse
software.
• A maximum of 30 points can be inputted
into the Pulse software.
• Maximum height of 13 ft. (3.96 m).
FIG. 21
NOTE: *TLM Offset is the distance from the
maximum height to the shoulder above the
threads on TLM.
