TLM Display
3A9522A 7
Bad Measurement
If there is a communication error during a
read measurement (i.e., timeout), or the
status from the read measurement
command indicates an issue, SENSOR E#
displays. The # corresponds to the Sensor
Error Table.
SENSOR ERROR TABLE
Error Description
SENSOR E0
Invalid reading or sensor
communication error
SENSOR E1
No sensor PCBA detected
(damaged circuit board)
SENSOR E4 Invalid profile parameter
SENSOR E5
Measurement exceeds maximum
length
SENSOR E7 Registration error
SENSOR E8 Profile error
SENSOR E9
RF communication error (no
acknowledge or no signal)
SENSOR E10
Internal error (report to Graco tech
support)
SENSOR E12 Sensor communication error
SENSOR E13 Sensor communication error
SENSOR E14 Sensor communication error
SENSOR E15 Sensor communication error
