Technical Data
311075R 71
All other brand names or marks are used for identification purposes and are trademarks of their respective owners.
Tank Capacity 7 gal. (26.5 liters) each (nominal)
Fluid Outlets Component A (ISO): -5 JIC male
Component B (RES): -6 JIC male
Fluid Circulation Returns Component A (ISO): -5 JIC male
Component B (RES): -6 JIC male
Air Inlet 1/4 in. quick-disconnect industrial type pin fitting
Air Outlet 1/4 npsm(m)
Gun Compressed Air
Requirements
Fusion Gun (purge air and operating air): 4 scfm (0.112 m
3
/min)
2K Ultra-Lite Gun with disposable mixer kit: 14 scfm (0.392 m
3
/min),
with air spray valve fully open
2K Ultra-Lite Gun with joint fill kit: 2 scfm (.056 m
3
/min)
Hose Markings A Side: Red
B Side: Blue
Weight (empty) approximately 160 lb (72 kg), depending on model
Wetted Parts Aluminum, stainless steel, carbon steel, brass, carbide, chrome,
chemically resistant o-rings, PTFE, ultra-high molecular weight poly-
ethylene
