Graco Simulation XM Instructions - Parts

Related Manuals
2 3A2988C
Contents
Related Manuals ...........................2
Warnings .................................3
Keep Components A and B Separate .........5
Changing Materials .......................5
Component Identification ....................6
Overview ..................................7
Installation ................................8
FluidInlets..............................8
Solvent Inlet ............................8
FluidOutlet .............................8
Heated Manifold .........................8
Mounting ...............................8
Grounding ................................9
Flush Before Using Equipment ...............9
Operation ................................10
Pressure Relief Procedure ................10
Flush .................................11
Dispensing and Spraying .................12
Volume Balancing the Mix Manifold .........13
Maintenance ..............................15
CleanStaticMixers ......................15
CleanMixManifoldOutlet.................15
Troubleshooting ..........................16
Repair ...................................17
Check Valves ..........................17
Parts ....................................18
262890 Mix Manifold .....................18
Technical Data ............................21
Graco Standard Warranty ...................22
GracoInformation ......................... 22
Related Manuals
Manuals are available at www.graco.com. Component
Manuals in English:
Manual Description
3A2776 XM PFP Operation
3A2989 XM PFP Repair - Parts
3A2799 XHF Spray Gun

Graco Simulation XM Specifications

General

Brand	Graco
Model	Simulation XM
Category	Paint Sprayer
Language	English
