Component Identification
309665L 5
Component Identification
English
1 ON/OFF switch
2 Drain tube
3 Siphon tube
4 Pressure control
5 Filter
6 Trigger lock
7Pump
8 Fluid outlet
9 Prime/Spray valve
10 Service Tag (below sprayer frame)
Model 233960 shown
6
1
8
9
5
4
3
2
7
