Startup
14 3A9014A
Startup
1. Install the cup onto the sprayer as
follows:
a. Verify Pump Filter is installed and
clean.
b. Align VacuValve (on Cup Lid) with
Prime Knob (on sprayer).
c. Push cup assembly onto the
sprayer, twist to lock.
2. Prime the pump as follows:
a. Verify Prime Knob is pointed down
to PRIME position.
b. Plug sprayer into a grounded
power source.
c. Open the VacuValve cap and
gently squeeze the FlexLiner until
no more air bubbles appear in the
VacuValve.
NOTE: Tilt the sprayer such that the
VacuValve is the highest point so that all air
in the FlexLiner can be fully evacuated.

Graco TrueCoat 360 Specifications

General

Type	Airless Paint Sprayer
Power Source	Electric
Max Tip Size	0.015 inches
Spray Pattern	Adjustable
Nozzle Size	0.015 inches
Material	Plastic and Metal
Maximum Pressure	1500 PSI
Voltage	120V
Hose Length	Not applicable
