Graco TrueCoat 360 - Parts List- Variable Speed Premium

Replacement Parts
3A9014A 33
Parts List- Variable Speed Premium
Ref. Sprayer Name
Order
Part No.
Description
1 All 18F756 Complete pump assembly includes 2, 3, 5, 6, 7, 8
2 All 16Y425 O-ring
3 All
18A886 Filter, pump, paint
18F209 Filter, pump, stain
5 All 117059 O-ring
6 All 17A402 Prime Pump/Spray valve includes qty. 1 of ref. 5
7 All 17A221 Kit, Prime Pump/Spray knob includes qty. 1 of ref. 8
8 All 119236 Screw, T-15 (torque 8-10 in-lb / 0.9-1.1 N•m)
9 All
18F520 Kit tips, paint includes 3 (CAN models order CAN520)
18F519 Kit tips, stain includes 3 (CAN models order CAN519)
10 All 16X880 Reciprocator assembly
12 All 17F068
Control, electronic, variable speed, 120 V includes motor, air
duct, power cord and switch
13 All 17D844 Adapter, variable speed control
14 All 16W846 Support, cup, 32 oz.
15 All 17A226 Kit, 32 oz., FlexLiner (3-pack)
16 All 17R821
Kit, cup assembly includes 14, qty. 1 of ref. 15, 16a, 17, qty.
1 of ref. 18
16a All 17M879 Plug, cup lid, not shipped with sprayer (not shown)
17 All 18F759 Lid, cup includes qty. 1 of ref. 18
18 All 17P712 VacuValve cap, 3-pack
19 All 17A227 Kit, enclosure includes qty. 13 of ref. 8
20 All 16Y680 Label, USA
22 All 16Y678 Label, control
23 ▲ All 16Y636 Label, warning and model number, side (not shown)
24 All 18C042 Label, brand, TrueCoat 360 VSP
25 ▲ All 17A198 Label, warning, cord (not shown)
26 All 18F449 Case, storage
27 All 17F069
Kit, enclosure, variable speed includes sight glass, includes
13, 29, qty. 2 of ref 8
28 All 17F364 Kickstand
29 All 17D843 Sight glass
30 All 18B057 Kit, funnel, strainer includes 2
31 All 25T467 Lubricant, seal lube
32 All 17K515 Label, A+ Service (not shown)
33 All 18B058 Spout, pour
- - ▲ All 179960 Card, medical alert (not shown)
- - - All 243104 Pump Armor, 32 oz (not shown)
- - - All 18C045 Tag, hang, tip (not shown) (CAN models order 18F613)
- - - All 17F518 Kit, 42 oz. cup (not shown)
- - - All 17F005 Kit, 42 oz. FlexLiner (3-pack) (not shown)
▲ Replacement safety labels, tags, and cards are available at no cost.
